按需式压电喷头
Consult Now
Printing style
Monochrome duplex Dual-color duplexResolution
600x600dpi 600x1200dpi
Max. printing speed
600x600dpi 120(m/min) 600x1200dpi(m/min)
Front-back registration
±0.1mmInkjet head
Drop-on-Demand piezoelectric nozzleInk type
Water based pigment inkDrying
Infrared drying (full automatic adjustment on printing speed)Operation interface
Visual operation interfaceMax. media width
440mm 560mm 660mmMax. printing width
432mm 540mm 648mmMedia thickness
45-165(g/㎡)Media type
Digital printing paper, inkjet coating paper, newsprint, wall paper, etc.Max. roll diameter
1.27mMechanical platform
Max.25KW红外干燥
Max.6KWDigital control system
Max.5.5KWTemperature
Range 22.5-27.5°C Best working temperature 25°CHumidity
Range 40-70% Best working temperature 50-60%RHSize & Weight
Size:11000x3500x2200mm weight:9500KG
Optional
Decoiling system
Paper dust removal system
Printing main unit
High effciency temperaturecontrol system
Nozzle compensation
Paper positioning system
Anti-static system
Cut stacked system
Winding system
