单元搭载32个京瓷80K循环压电喷头，适用铜版纸解决方案，打印普通铜版纸不用预涂，实现1200×1200dpi高精度打印，其墨点仅有1.5-2PL，具有墨点小，容易干的优点。
Consult Now
Printing style
CMYK duplexResolution
1200x600dpi 1200x960dpi 1200x1200dpiMax. printing speed
600x1200dpi150m/min 1200x1200dpim/minCMYK registration
±0.05mmFront-back registration
±0.1mmInkjet head
Drop-on-Demand piezoelectric nozzleInk type
Water based pigment inkDrying
Infrared drying (full automatic adjustment on printing speed)Operation interface
Visual operation interfaceMax. media width
440mm 560mm 660mmMax. printing width
432mm 552mm 652mmMedia thickness
45-165(g/㎡）Media type
Digital printing paper,art paper,offset paper,inkjet coated paper,etcMax. roll diameter
1.27mMechanical platform
Max.35KWInfrared drying
Max.40KWDigital control system
Max.8KWTemperature
Range 22.5-27.5°C Best working temperature 25°CHumidity
Range 40-70% Best working temperature 50-60%RHSize & Weight
Size:14800x4000x2000mm weight:13000KG
Optional
Decoiling system
Paper dust removal system
Printing main unit
High effciency temperature control systen
Nozzle compensation
Paper positioning system
Anti-static system
Cut stacked system
Winding system
Image detection system
